Operate characteristic

Proportional

Emission standard/Altitude

EPA4/EU5/China Tier 4/1200m

Fuel consumption

239g/kW-h

Type/Displacement

4 cylinder/2.19L

Model

SG900D

Capacity

9t×0.7m

Working radius

8.5m×0.5t

Max lifting height

10.3mX1.5t

Hook speed

0-8m/min (4 fall）

Rope type

Φ10mm×80m

Boom form

3+2 sections

Boom length/Time

5.6m-10.9m/60sec

Boom angle/Time

-5°-55°/50sec

Walking way

Hydraulic

Speed

0-8km/h

Grade ability

Without load 5.7°(10%), With load-2.9°（5%）

Rear wheel（Drive,steering）

2 x 6.50 R10”（Pneumatic）

Front wheel（Bearing wheel）

4 x 21x8-R9”（Solid）

Turning radius

3.62m

Model

4TNV88（Yanmar）

Rated output

29.1kw/2400min-1

Starting method

Electric

Operating temperature

-5°C~40°C

Fuel/Volume

Diesel/60L

Battery capacity

12v 90AH

Sound level

Rated speed≤93dBA (1m)

Type of operation

Steering wheel+Universal Handel/Remote

Length×Width×Height

4900mm×1800mm×2500mm

With optional device

9000kg
